Description
FEATURES
- Does not occupy much space because it is compact and desktop type.
- Dialog type operation. Easy to operate.
- Sample can be set in up to 10 cups. (40 cups optional)
- Sample table can be mounted/dismounted by one touch.
- Fully automatic operation assures labor saving for line use.
- Simple construction for easy maintenance.
- When the machine stops due to an error, an error message is displayed on the monitor screen.
- Equipped with machine test function to check operation of each part.
- Full automatic operation of Method B.
Specifications
| Model | D-M |
| Sample cups |
|
| Temperature range | max. 300°C |
| Test loads | 0.325, 2.16, 5.0, 10.0kg |
| Sample feeding | Automatic |
| Weight lifting | Automatic |
| Residue emptying | Automatic |
| Cylinder cleaning | Automatic |
| Piston cleaning | Automatic |
| Orifice (Die) cleaning | Automatic |
| Data processing unit | Provided (PC & Software) |
| Option |
|
| Power supply | Single-phase, AC100V, 50/60Hz, 1.5kVA |
| Compressed air requirement | 0.6MPa |
| Dimensions | W900 × D700 × H1060mm |
| Mass (Approx.) | 320kg |
Related standards
| ISO 1133 | Plastics-Determination of the melt mass-flow rate (MFR) and melt volume-flow rate (MVR) of thermoplastics |
| ASTM D1238 | Standard Test Method for Melt Flow Rates of Thermoplastics by Extrusion Plastometer |
