No. 260 Strograph™ VGS-series Universal Testing Machine (max. 5kN)

(Dual column Universal Testing Machine, max. 5kN)

Universal testing machines (UTM) incorporating multi CPU control for testing tensile strength, compression strength and bending strength, etc. of various materials.

Add To Enquiry
Loading...

Description

Specifications

Force capacity Max. 5kN
Crosshead travel 830mm
Maximum speed 1000mm/min.
Minimum speed 0.0005mm/min.
Dimensions W630 x D470 x H1330mm
Mass (Approx.) 105kg
Power supply Single-phase, AC100V, 50/60Hz, 0.7kVA (or specify)

Related standards

ISO 527-1

JIS K 7161, K 7113, K 7127, K 6251
