Description
Specifications
| Measurement method | Load cell |
| Measuring load range | 0.0 to 30.0N |
| Sticking load | 2 to 5N (Standard)
Max. 20N (Optional) |
| Number of times to perform measurement | 1, 3, 5 (Selectable) |
| Sticking time | 0.0 to 99.9 sec. |
| Specimen mounting wheel down speed | 60mm/min., 1000mm/min. (Selectable) |
| Specimen mounting wheel separating speed | Wide speed: 5, 10, 50, 100, 500, 1000, 1500, 3000mm/min.
Low speed: 5, 7.5, 10, 15, 20, 25, 30, 50mm/min. High speed: 100, 500, 700, 1000, 1250, 1500, 2000, 3000mm/min. (Select one out of them) |
| Interface | R-232C |
| Dimensions | W300 × D330 × H510 mm |
| Mass (Approx.) | 18kg |
| Power supply | Single-phase, AC100 to 240V, 50/60Hz, 0.5kVA |
