Description
Specifications
| Model | H-50 | H-100/H-200 |
| Application | Coatings | Plastic sheets |
| Falling height | Max. 500mm | Max. 1000mm (H-100)
Max. 2000mm (H-200) |
| Falling weight | 300g, 500g, 1000g | 1000g, 2000g |
| Impact head | R1.59mm
R3.18mm R4.76mm R6.35mm R12.7mm |
R7.9mm |
| Receive block | R1.59 / R3.18mm
R4.76 / R6.35mm Flat |
R8.1 / R15.2mm |
| Dimensions | W460 x D300 x H760mm | W450 x D300 x H1260mm (H-100)
W460 x D300 x H2260mm (H-200) |
| Mass (Approx.) | 20kg | 25kg (H-100)
30kg (H-200) |
| Related standards | JIS K 5600-5-3 | ASTM D2794
JIS K 5600-5-3 |
