TOYOSEIKI : No. 107 Compression Tester, T5-F (Compression Testing Machine for Box and Carton)

The Compression Tester evaluates compression strength of large size containers such as boxes and cartons used for packaging, etc.

Description

Force capacity	Max. 50kN
Stroke	1500mm
Maximum speed	100mm/min.
Minimum speed	0.5mm/min.
Dimensions	W2080 x D1200 x H2840mm
Mass (Approx.)	2300kg
Power supply	Three-phase, AC200V, 50/60Hz, 5.2kVA (or specify)

JIS Z 0212
